IBM System x3650 M4 Type 7915 Problem Determination And Service Guide

Table 16. Memory mirrored channel mode DIMM population sequence (continued)
Number of DIMMs
Number of installed
microprocessor DIMM connector
Ninth pair of DIMMs 2 14, 17
Tenth pair of DIMMs 2 20, 23
Eleventh pair of DIMMs 2 15, 18
Twelfth pair of DIMMs 2 19, 22
Note: DIMM connectors 3, 6, 7, 10, 15, 18, 19, and 22 are not used in memory mirrored
channel mode when UDIMMs are installed in the server.
Memory rank sparing
The memory rank sparing feature disables the failed memory from the system
configuration and activates a rank sparing DIMM to replace the failed active DIMM.
You can enable rank sparing memory in the Setup utility, select System Settings →
Memory. For more information, see “Using the Setup utility” on page 301. When
you use the memory rank sparing feature, consider the following information:
v The memory rank sparing feature is supported on server models with an Intel
Xeon
™
5600 series microprocessor.
v The maximum available memory is reduced when memory rank sparing mode is
enabled.
The following diagram lists the DIMM connectors on each memory channel.
Follow the installation sequence for rank sparing mode:
v Install at least one quad-rank DIMM in a channel.
v Install at least two single-rank or dual-rank DIMMs in a channel.
You can install DIMMs for the microprocessor 2 once the microprocessor 2 is
installed. You do not need to wait until all of the DIMM connectors for
microprocessor 1 are filled. The following table shows the installation sequence for
memory rank sparing mode:
Table 17. Memory rank sparing mode DIMM population sequence
Number of DIMMs
Number of installed
microprocessor DIMM connector
First pair of DIMMs 1 1, 2
Second pair of DIMMs 1 4, 5
Third pair of DIMMs 1 8, 9
Fourth pair of DIMMs 1 11, 12
Fifth pair of DIMMs 1 7, 10
Sixth pair of DIMMs 1 3, 6
Seventh pair of DIMMs 2 13, 14
DIMM 3 DIMM 9 DIMM 6 DIMM 12 DIMM 2 DIMM 8 DIMM 5 DIMM 11 DIMM 1 DIMM 7 DIMM 4 DIMM 10
CH1Ch2 CH0Ch3
Microprocessor 1
CPU1
DIMM 15 DIMM 21 DIMM 18 DIMM 24 DIMM 14 DIMM 20 DIMM 17 DIMM 23 DIMM 13 DIMM 19 DIMM 16 DIMM 22
CH1Ch2 CH0Ch3
Microprocessor 2
CPU2
Figure 2. Connectors on each memory channel
Chapter 5. Removing and replacing server components 255
