Figure 40. Side rails installed

3. Place the library at the front of the rack on the support angles of the rails and push it into the rack to

the back stop.

Figure 41. Sliding the library into the rack

4. If you are installing multiple modules, verify that this module is installed directly above or below its

adjacent module and is contained within the correct 3U volume. Remove the tape that is covering the

alignment pin lock/unlock lever on the rear of each module. The gap between modules must be less

than 4 mm.

IBM Condential

Chapter 3. Installing59
