Figure 38. Correct connect
or locations
c.
Repeat st
ep
b
on the right and left rack posts in the rear of the rack.
d.
Mount the LH Rackmount rail to the connect
ors. See Figure 39 on page 58.
e.
Repeat step
d
with the RH Rackmount R
ail.
Figure 39. Mounting the rails to the c
onnectors
