Section 4 - Installation
INSTALLATION
36 Installation and Maintenance
4.1.8 Removal of Transport Bracket
Figure 38. Transport Bracket Installation
ᘐ CAUTION: The compressor transportation support
bracket must be removed before the compressor is
operated. If it is not removed the bracket will damage the
compressor.
For 10, 12, & 14kW models as delivered, the compressor
is supplied with a transportation support bracket to prevent
damage during transport. Once the product is installed, this
bracket must be removed before operating the product by
following the steps below
1. Remove the four screws that attach the transportation
support bracket.
2. Remove the transportation support bracket.
3. Dispose of the bracket and screws. Refer to local authority
regulations for correct waste disposal.
