Section 4 - Installation
INSTALLATION
31
Installation and Maintenance
ᘐ CAUTION: Use a suitable means of transporting the
Heat Pump. The appliance MUST remain upright and not
be tilted more than 45° to prevent damage to the internal
sealed circuit of the Heat Pump.
ᘐ CAUTION: The product is not to be manoeuvred
via the packaging straps. The packaging straps are not
designed to carry the weight of the packaged unit and
will may break potentially causing injury to handlers or
damage to the product.
Packaging Symbols
The below symbols and conditions must always be followed
for the packaged product.
Do not clamp from these sides when handling.
2
Vertical stacking limit x 2
Do not tilt the package
This package is to be kept upright
Product must be treated as fragile
Flammable contents
Keep package away from water and rain
Product should not be discarded as unsorted waste but
must be sent to separate collection facilities for recovery
and recycling
ᘐ WARNING: Packaging straps are tightly secured and
can release a lot of kinetic energy when cut. Hold straps
rmly and apply caution when cutting and keep body
away during cutting to avoid injury.
The packaging is to be removed by following the below
sequence:
1. Remove packaging straps by cutting them away from the
body.
2. Lift lid from packaging and evenly lift cardboard surround
sleeve.
3. Remove polystyrene top plate and accessories pack.
ᘐ WARNING: The protective plastic bag can
accumulate a lot of static charge. Appropriate measures
should be taken in hazardous areas.
4. Remove protective plastic bag from the Heat Pump and
secure with the rest of the packaging.
5. Once the Heat Pump is ready to be mounted, remove the
6. It is the responsibility of the system installer to correctly
dispose and recycle the product packaging.
After the product is unpacked, make sure that all the contents
are present.
Quantity Item Description
1 HP290 Monobloc Heat Pump
1 Documentation Package
1 ErP Label
1 Hardware Pack
1 Flow and Return adaptors (2 pack)
ⓘ IMPORTANT: If there are any missing items, contact
Ideal Heating.
4.1.3 Receival and Unpacking
4.1.4 Lifting and Handling
ᘐ WARNING: The surface of the evaporator is sharp.
Care should be taken when handling the product and
appropriate protective equipment used.
ᘐ CAUTION: Use a suitable means of transporting the
Heat Pump. The appliance MUST remain upright and not
be tilted more than 45° to prevent damage to the internal
sealed circuit of the Heat Pump.
Handlers must be aware and capable of good manual
handling techniques and practise them during the lifting and
handling of the heat pump. Weight of the products can be
found in Table 12.
Table 12 Weights of Unpackaged Units
HP290 Unit 4.5 6 8 10 12 14
Unpackaged Weight Kg 90 117 135
Prior to transporting and handling the product, the movement
route must be planned, and the mounting foundation be
prepared. It must be made sure that the movement route can
handle the weight of the product and lifting equipment.
Once moved onto the foundation, the heat pump is to be
loosening over time. There must be some method of vibration
absorption to prevent vibration from damaging the mounting
foundation.
