IDS X Series Installer Manual

IDS X-Series Installer Manual 700-398-02H Issued July 2013
17
EXAMPLE:
[INSTALLER CODE] [*] [0] [*] [VALUE] [*]
NOTE:
When you enter a standard location and press the [*] key, you will NOT be entering a sub-location – as there is
no sub-location to enter. What will happen is that you will scroll through the information in that location. If you
enter a digit, you will be changing the information stored in that position of the location, or the location itself.
EXAMPLE:
If you want to scroll through all the entries within a location with a LED keypad, you will input the following
data:
[INSTALLER CODE] [*] [LOCATION NO.] [*] [*] [*] [*], etc.
Scrolling through with the [*] key will show you all the numbers in a location. At the end of the allowed
locations, there will be a long beep to indicate that you are back at entry one of the location.
If you go to location 61 – Primary Account Codes, and then press the [*] key again followed by a digit, you will
be changing just the digit in that string.
Programming Extended Locations
The following steps show you how to program extended locations. These are locations that have sub-locations.
There are two ways to program extended locations: the string method or by using sub-locations.
Using the String Method
Using the string method is a fast and efficient way to program the X-series family. By filling in the
programming sheets, the installer can first plan the installation, and then very quickly program
multiple locations.
1. Ensure that the panel is in program mode - the READY LED will be flashing.
2. Enter the [LOCATION NO.] of the program location that you wish to view or change.
3. Press the [*] key. The READY LED is on and the ARM and AWAY LEDs will flash.
4. The first sub-location of data on the LED keypad is displayed.
5. Enter the [STRING] for the program locations that you wish to change.
6. Press the [*] key, a long beep indicates a valid data entry.
7. The ARM and AWAY LEDs turn off and the READY LED will flash for the next location.
8. If you do not wish to change the data within this location, press the [#] key. The READY LED will
continue flashing and the ARM and AWAY LEDs will turn off.
9. Repeat steps 2 - 7 until all extended locations have been programmed.
10. Press the [#] key again to exit from program mode.
11. The READY LED will stop flashing and the panel will return to standby mode.
NOTE: To view the rest of the string, use the [*] key to advance one sub-location at a time. At the end of the
allowed locations, there will be a long beep to indicate that you are back at entry one of the location.
The mode automatically reverts to Sub-location Mode - see “Using Sub-locations”.
When programming using the string method, any attempt to enter invalid data will result in an error beep (3
short beeps).
The AWAY and ARM LEDs will remain on after the error beeps. Re-enter the correct data. There is no need to
press the [#] key.
EXAMPLE:
[INSTALLER CODE] [*] [1] [*] [0102040404040404] [*]
