IDS X-Series Installer Manual 700-398-02H Issued July 2013
53
[INSTALLER CODE] [*] [LOCATION] [*] [USER] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are enabled
Refer to section 0 Using Sub-locations to see how to scroll through sub-location using the [*] key.
NOTE: The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
Cancelling a Silent Alarm or Silent Panic will not cause the cancel siren code to be reported.
LOCATIONS 374 Quick Close Reporting Codes
Locations to enter reporting codes if you want to report when a user uses the quick arm key to arm, to the
control room. This is for formats other than Contact ID and SIA. Default is 00.
LOCATIONS 375 Quick Stay Reporting Codes
Locations to enter reporting codes if you want to report when a user uses the quick stay arm key to arm, to the
control room. This is for formats other than Contact ID and SIA. Default is 00.
Programmable Outputs
Output Disarm Clear
LOCATION 380 Clear Programmable Onboard Outputs on Disarming
This bitmapped location allows onboard programmable outputs 1-5 to be cleared (set low) on
disarming. The output/s to be cleared will be displayed by zone number LEDs. The programmable outputs will
clear when ANY partition is disarmed. Refer to Table 30 to view which zone number LED corresponds to which
onboard output.
Regardless of which partition they are allocated to, disarming any partition will clear these outputs.
Table 30: Clear Programmable Onboard Outputs Data
LED
Disarm Clear Output
LED
Disarm Clear Output
LED
Disarm Clear Output
1
Output 1
3
Output 3
5
Output 5
2
Output 2
4
Output 4
LOCATIONS 381 – 386 Clear Programmable Zone Expander Outputs on Disarming
This bitmapped location allows the 2 outputs of the 6 zone expanders to be cleared (set low) on
disarming. The output(s) to be cleared will be displayed by zone number LEDs. The programmable outputs will
clear when ANY partition is disarmed. Refer to Table 31 to view which zone number LED corresponds to which
zone expander output. These are only available on X64.
Each location represents a zone expander:
 Location 381 represents zone expander 1
 Location 382 represents zone expander 2
 Location 383 represents zone expander 3
 Location 384 represents zone expander 4
 Location 385 represents zone expander 5
 Location 386 represents zone expander 6
Table 31: Clear Programmable Zone Expander Outputs Data
LOCATION 389 Clear Programmable Keypad Outputs on Disarming
This bitmapped location allows the single outputs of the 8 keypads to be cleared (set low) on
disarming. The output/s to be cleared will be displayed by zone number LEDs. The programmable outputs will
clear when ANY partition is disarmed. Refer to Table 32 to view which zone number LED corresponds to which
keypad output.
Table 32: Clear Programmable Keypad Outputs Data
LED
Output
1
Output 1
2
Output 2
LED
Output
LED
Output
LED
Output
LED
Output
1
Keypad 1
3
Keypad 3
5
Keypad 5
7
Keypad 7
2
Keypad 2
4
Keypad 4
6
Keypad 6
8
Keypad 8

IDS X Series Specifications

General

Key Type	Tactile
Backlight	Yes
Operating Voltage	12VDC
Weight	150g
Operating Temperature	-10°C to +55°C
