IDS X-Series Installer Manual 700-398-02H Issued July 2013
9
2. Introduction to the IDS X-Series
Thank you for purchasing an IDS Alarm Panel.
The IDS X-Series alarm is a versatile, Bylaw 25 compliant, expandable Alarm Panel. It comes in two versions,
X16 and X64. Both have up to 8 partitions and can have 8 keypads. The X16 can be expanded from 8 to16 zone
and the X64 from 8 to 64 zones. Most features are configurable and may be programmed directly through a
keypad or via serial PC connection or telephone system, using the IDSwift Download Software and appropriate
modem (P/N: 860-36-0001).
There are up to 64 programmable burglary zones on the X64, 16 programmable burglary zones on the X16. A
dedicated panic zone, monitored siren output, auxiliary power output, and 5 onboard programmable outputs
expandable to 25 on the X64, which may be programmed to perform various, trigger/switching functions are
available.
For correct operation, the IDS X-series panels must be used in conjunction with the specified transformer /
battery combination (ask your sales representative for a copy of the IDS Power Budget spreadsheet to identify
your needs) and appropriate peripheral sensors and signalling devices.
NOTE:
X-SERIES products are not compatible with any previous IDS products, such as the IDS816 and IDS1632.
Features of the IDS X-Series
Zones and Partitions:
 8 onboard zones, expandable to 16 onboard zones with a X-series 8-zone Plug-in Expander
(P/N: 860-06-X-08PI) – A very cost-effective 16 zone solution
 Further expandable to 64 zones with the use of up to 6 bus-wired X64 8-zone Unpowered Expander
modules (P/N: 860-06-X-08S) or 8 keypad zones - 1 per keypad
 All zones can be expanded with wireless receivers to receive signals from the Duevi range of wireless
detectors. All wireless zones are fully supervised.
 The system can also have a hybrid of wired and wireless zones totaling 64 zones for the X64 and 16
zones for the X16.
 8 partitions
 4 stay profiles per partition
Users:
 128 users
 Options to set user codes as Master, Duress, Maid, Arm only, Disarm only or Output Trigger.
System Options:
 Tamper reporting per zone using double end-of-line resistors (12K and 4K7)
 5 programmable outputs on the Alarm Panel, expandable to 25 when using zone expanders (2 per
expander), and keypads (1 per keypad)
 Event log (1000 events) date and time relative
 Auto arm/disarm capability per partition and by day of the week.
 No movement auto arm and medical reporting
 Panel firmware installer upgradable via serial data cable
 Telephone communicator that supports Ademco, FBI, Silent Knight, Contact ID, and SIA
 Fax defeat/answering machine override
 Dual reporting provides for duplicated reporting to two independent central base stations
 Split reporting to report to either 1 of 2 dual reporting number pairs
 Comprehensive lightening protection
 Dynamic battery self-test
 Low battery monitoring and cut-out circuit
 Dual power supply, with an independent battery charging circuit, means more onboard power for
simplified alarm installation
 Voice module support (860-06-X64-0412). Only version “D” hardware and above.
