Delays
LOCATION 230 Exit Delay Period (default = 0030)
The exit delay period is the amount of time between arming the panel and successfully exiting the premises
without violating Entry/Exit and Follower zones.
The exit delay will begin after the system is armed by either:
 Entering a valid user code
 Pressing the [1] key and holding it down until the system is armed
 Pressing the [6] key and holding it down until the system is armed
Enter a 4-digit exit delay period for each of the 8 partitions and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [2] [3] [0] [*] [PARTITION NO.] [*] [MMSS] [*]
The valid data range is: 00m00s – 59m59s.
Partition no. is: 1-8.
Refer to Using Sub-locations to see how to scroll from one sub-location to another using the [*] key.
LOCATION 231 Primary Entry Delay Period (default = 0030)
The primary entry delay begins after the violation of a Primary Entry/Exit zone. During this delay, it is
permissible to violate Follower zones without causing an alarm condition.
If a Follower zone is violated without a prior Entry/Exit zone violation, it will be treated as an Instant zone. If an
Instant zone is violated during this period, an alarm condition will immediately be registered.
Enter a 4-digit entry delay period for each of the 8 partitions and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [2] [3] [1] [*] [PARTITION NO.] [*] [MMSS] [*]
The valid data range is: 00m00s – 59m59s.
Partition no. is: 1-8.
Refer to Using Sub-locations to see how to scroll from one sub-location to another using the [*] key.
LOCATION 232 Secondary Entry Delay Period (default = 0030)
The secondary entry delay begins after the violation of a Secondary Entry/Exit zone. During this delay, it is
permissible to violate Follower zones without causing an alarm condition.
Enter a 4-digit entry delay period for each of the 8 partitions and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [2] [3] [2] [*] [PARTITION NO.] [*] [MMSS] [*]
The valid data range is: 00m00s – 59m59s.
Partition no. is: 1-8.
Refer to Using Sub-locations to see how to scroll from one sub-location to another using the [*] key.
Options to Configure Keypads
LOCATION 240 Keypad Partition (default = Partition 1)
Program this location to allocate each keypad to a partition. Enter the partition number to which each keypad,
with an ID 1-8, must be allocated. To view the ID of a keypad refer to location 243.
Enter 1 digit for each of the 8 keypads and program as an 8-digit string, followed by the [*] key.
[INSTALLER CODE] [*] [2] [4] [0] [*] [KEYPAD NO.] [*] [PARTITION NO.] [*]
The valid data range is: 1 – 8.
Partition no. is: 1-8.
Refer to Using Sub-locations to see how to scroll from one sub-location to another using the [*] key.

IDS X Series Specifications

General

Key Type	Tactile
Backlight	Yes
Operating Voltage	12VDC
Weight	150g
Operating Temperature	-10°C to +55°C
