15. Appendix
Extra Contact ID Zone Reporting Codes
When these values are entered into locations 304 to 307 the zone that now has this new value will report the
Contact ID code that is associated with it.
Value
CID
Description
Value
CID
Description
01
100
Medical Zone
3C
303
RAM Checksum bad Zone
02
101
Personal Emergency Zone
3D
304
ROM checksum bad Zone
03
102
Fail to report in Zone
3E
305
System reset Zone
04
110
Fire Zone
3F
306
Panel programming changed Zone
05
111
Smoke Zone
40
307
Self- test failure Zone
06
112
Combustion Zone
41
308
System shutdown Zone
07
113
Water flow Zone
42
309
Battery test failure Zone
08
114
Heat Zone
43
310
Ground fault Zone
09
115
Pull Station Zone
44
311
Battery Missing/Dead Zone
0A
116
Duct Zone
45
312
Power Supply Overcurrent Zone
0B
117
Flame Zone
46
313
Engineer Reset User
0C
118
Near Alarm Zone
47
320
Sounder/Relay Zone
0D
120
Panic Zone
48
321
Bell 1 Zone
0E
121
Duress User
49
322
Bell 2 Zone
0F
122
Silent Zone
4A
323
Alarm relay Zone
10
123
Audible Zone
4B
324
Trouble relay Zone
11
124
Duress – Access granted Zone
4C
325
Reversing relay Zone
12
125
Duress – Egress granted Zone
4D
326
Notification Appliance Ckt. # 3 Zone
13
130
Burglary Zone
4E
327
Notification Appliance Ckt. #4 Zone
14
131
Perimeter Zone
4F
330
System Peripheral trouble Zone
15
132
Interior Zone
50
331
Polling loop open Zone
16
133
24 Hour (Safe) Zone
51
332
Polling loop short Zone
17
134
Entry/Exit Zone
52
333
Expansion module failure Zone
18
135
Day/night Zone
53
334
Repeater failure Zone
19
136
Outdoor Zone
54
335
Local printer out of paper Zone
1A
137
Tamper Zone
55
336
Local printer failure Zone
1B
138
Near alarm Zone
56
337
Exp. Module DC Loss Zone
1C
139
Intrusion Verifier Zone
57
338
Exp. Module Low Batt. Zone
1D
140
General Alarm Zone
58
339
Exp. Module Reset Zone
1E
141
Polling loop open Zone
59
341
Exp. Module Tamper Zone
1F
142
Polling loop short Zone
5A
342
Exp. Module AC Loss Zone
20
143
Expansion module failure Zone
5B
343
Exp. Module self-test fail Zone
21
144
Sensor tamper Zone
5C
344
RF Receiver Jam Detect Zone
22
145
Expansion module tamper Zone
5D
350
Communication trouble Zone
23
146
Silent Burglary Zone
5E
351
Telco 1 fault Zone
24
147
Sensor Supervision Failure Zone
5F
352
Telco 2 fault Zone
25
150
24 Hour Non-Burglary Zone
60
353
Long Range Radio xmitter fault Zone
26
151
Gas detected Zone
61
354
Failure to communicate event Zone
27
152
Refrigeration Zone
62
355
Loss of Radio supervision Zone
28
153
Loss of heat Zone
63
356
Loss of central polling Zone
29
154
Water Leakage Zone
64
357
Long Range Radio VSWR problem Zone
2A
155
Foil Break Zone
65
370
Protection loop Zone
2B
156
Day Trouble Zone
66
371
Protection loop open Zone
2C
157
Low bottled gas level Zone
67
372
Protection loop short Zone
