20. Programming Quick Reference Guide
Entering Program Mode
 [#] [INSTALLER CODE] [*] to enter program mode.
 A long beep will confirm entry.
 The READY LED will flash.
Programming Standard Locations
 The panel is in program mode – the READY LED is flashing.
 [LOCATION NUMBER] [*]
 The READY LED is solid on, and the AWAY LED will flash.
 Either [NEW DATA] [*] or [#] to exit.
 If data is entered, a long beep will confirm entry.
 In both instances, the READY LED will to flash and the AWAY LED will turn off.
 [#] to exit.
 The READY LED will stop flashing.
 The panel is now in standby mode.
Programming Extended Locations with Strings
 Panel is in program mode – the READY LED is flashing.
 [LOCATION NUMBER] [*]
 The READY LED is solid on, and the ARM and AWAY LEDs will flash.
 [STRING] [*]
 The ARM and AWAY LEDs turn off, and the READY LED will flash.
 If you do not want to change data press [#].
 The READY LED will continue to flash, whilst the ARM and AWAY LEDs turn off.
 [#] to exit.
 The READY LED will stop flashing.
 The panel is now in standby mode.
Programming Extended Locations with Sub-locations
 Panel is in program mode – the READY LED is flashing.
 [LOCATION NUMBER] [*]
 The READY LED is solid on, and the ARM and AWAY LEDs will flash.
 [SUB-LOCATION NUMBER] [*]
 The READY and ARM are solid on, and AWAY is flashing.
 [NEW DATA] [*]
 The READY LED is solid on, and the ARM and AWAY LEDs will flash.
 [#] if you do not wish to make changes.
 The READY is flashing, and the ARM and AWAY LEDs turn off.
 [#] to exit current location.
 The READY is flashing, and the ARM and AWAY LEDs turn off.
 [#] to exit.
 The READY LED will stop flashing.
 The panel is now in standby mode.
Programming a Bitmapped Location
 Panel is in program mode – the READY LED is flashing.
 [LOCATION NUMBER] [*]
 The READY LED is solid, and the AWAY LED flashes.
 [#] to exit current location.
 READY is flashing.
 [#] to exit.
 The READY LED will stop flashing.
 The panel is now in standby mode.

IDS X Series Specifications

General

Key Type	Tactile
Backlight	Yes
Operating Voltage	12VDC
Weight	150g
Operating Temperature	-10°C to +55°C
