IDS X-Series Installer Manual 700-398-02H Issued July 2013
LOCATION 26 Day of Week to Start Daylight Saving (default = 1)
Select the day of the week for Daylight Saving to commence, as per Table 14.
Table 14: Day of Week Data
[INSTALLER CODE] [*] [2] [6] [*] [DAY] [*]
LOCATION 27 Week of Month to Start Daylight Saving (default = 1)
Select the week of the month for Daylight Saving to commence as per Table 15. To set the last week
of each month, set the value to 5.
Table 15: Week of Month Data
[INSTALLER CODE] [*] [2] [7] [*] [WEEK] [*] The valid data range is: 1 – 5.
LOCATION 28 Month to End Daylight Saving (default = 0)
Select the month as per Table 13, to end Daylight Saving.
[INSTALLER CODE] [*] [2] [8] [*] [MONTH] [*]
The valid data range: 1 – 12, with 0 to disable.
NOTE: If this location is disabled, then by default, locations 29 and 30 will also be disabled. This means that
even if you put values into locations 29 and 30, daylight savings will not start.
LOCATION 29 Day of Week to End Daylight Saving (default = 1)
Select the day of the week as per Table 14, to disable Daylight Saving.
[INSTALLER CODE] [*] [2] [9] [*] [DAY] [*]
The valid data range is: 1 – 7.
LOCATION 30 Week of Month to End Daylight Saving (default = 1)
Select the week of the month as per Table 15, to disable Daylight Saving.
[INSTALLER CODE] [*] [3] [0] [*] [WEEK] [*]
The valid data range is: 1 – 5.
LOCATION 31 Daylight Saving Time Offset (default = 60)
Enter the daylight saving time offset that will be in force while daylight saving is enabled.
[INSTALLER CODE] [*] [3] [1] [*] [DAYLIGHT SAVING TIME OFFSET] [*]
The valid data range is: 0 – 250.
Miscellaneous – Advanced
LOCATION 32 Auto Test Report Interval (default = 7)
The value programmed into this location determines the duration of time between Automatic
System Tests. Input the value as per Table 16.
[INSTALLER CODE] [*] [3] [2] [*] [AUTO TEST REPORT INTERVAL] [*]
Table 16: Auto Test Interval Data
