IDS X Series Installer Manual

IDS X-Series Installer Manual 700-398-02H Issued July 2013
55
Table 35: Default Programmable Events Data
Loc
Event
Default
Output
Default
Action
390
Close Programmable Output Event
Output 3 [03]
Set High [00]
391
Stay Close Programmable Output Event
Disabled [00]
392
Open Programmable Output Event
Output 3 [03]
Set Low [01]
393
Cancel Programmable Output Event
Disabled [00]
394
Alarm Restoral Programmable Output Event
Disabled [00]
395
Bypass Programmable Output Event
Disabled [00]
396
Forced Arm Programmable Output Event
Disabled [00]
397
Zone Tamper Programmable Output Event
Disabled [00]
398
Zone Tamper Restoral Programmable Output Event
Disabled [00]
399
Zone Shutdown Programmable Output Event
Disabled [00]
400
Zone Shutdown Restoral Programmable Output Event
Disabled [00]
401
Keypad Panic Programmable Output Event
Output 1 [01]
Pulse High [02]
402
Keypad Fire Programmable Output Event
Output 4 [04]
Pulse High [02]
403
Keypad Medical Programmable Output Event
Output 5 [05]
Pulse High [02]
404
Keypad Lockout Programmable Output Event
Disabled [00]
405
Duress Programmable Output Event
Output 1 [01]
Pulse High [02]
406
Verifies Alarm Programmable Output Event
Disabled [00]
407
Burglary Programmable Output Event
Output 2 [02]
Pulse High [02]
408
Panic Programmable Output Event
Output 1 [01]
Pulse High [02]
409
Fire Programmable Output Event (Refer to Table 5)
Output 4 [04]
Pulse High [02]
410
Tamper Zone Programmable Output Event
Disabled [00]
Table 36: Default Programmable Events Data with no Default Action
Loc
Event
Default Output
411
Siren Programmable Output Event
Disabled [00]
412
Strobe Programmable Output Event
Disabled [00]
413
Chime Programmable Output Event
Disabled [00]
414
Arm Follow Programmable Output Event
Disabled [00]
NOTE: Once a programmable output has been enabled, the default action will be Pulse High [02].
Zone Programmable Output Events
The following locations are used to program the various zone outputs.
LOCATIONS 415 – 422 Zone Programmable Output Events
An output can be assigned to a zone so when the zone causes an alarm condition, the chosen output performs
the selected option. A list of available actions and their corresponding values is shown in Table 34.
Table 36 Regardless of the action selected for a particular output, if it is programmed to clear on disarming of
the panel (locations 380-389), the output will revert to clear (set low) after any partition disarmed.
Each location represents a set of 8 zones:
 Location 415 zones 1-8
 Location 416 zones 9-16
 Location 417 zones 17-24
 Location 418 zones 25-32
 Location 419 are zones 33-40
 Location 420 zones 41-48
 Location 421 zones 49-56
 Location 422 zones 57-64
Enter a 4-digit output and action for each of the 8 zones and program as 32-digit strings, followed by
the [*] key.
[INSTALLER CODE] [*] [4] [1] [5] [*] [ZONE NO.] [*] [OUTPUT] [ACTION] [*]
Refer to Programming Standard Locations to see how to scroll through data in a location using the [*] key.
