IDS X-Series Installer Manual 700-398-02H Issued July 2013
41
LOCATION 241 Keypad Display Start Zone (default = Zone 1)
The zones which a particular LED keypad displays is determined by programming the keypad start zone
location. The number programmed into this location is the zone which will be assigned to LED 1 on the keypad.
The keypad will display subsequent zones in order. The keypad will only display zones belonging to its partition.
Enter a 2-digit display start zone (01 – 64) for each of the 8 keypads and program as a 16-digit
string, followed by the [*] key.
[INSTALLER CODE] [*] [2] [4] [1] [*] [KEYPAD NO.] [*] [START ZONE] [*]
The valid data range is: 01 – 64.
Refer to Using Sub-locations to see how to scroll from one sub-location to another using the [*] key.
NOTE: This only applies to LED keypads and not LCD keypads.
LOCATION 242 Keypad Zone Number (default = 0 i.e. Disabled)
A keypad zone must be allocated to any zone number (1 – 64), before it can be used. The corresponding zone
type must be programmed in locations 1 – 8 and the properties configured in locations 101 – 164. If you
configure a keypad to a zone number that is already a wired zone, then the keypad will take priority on the
zone number.
Enter a 2-digit zone number (01 – 64) for each of the 8 keypads and program as a 16-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [2] [4] [2] [*] [KEYPAD NO.] [*] [ZONE NO.] [*]
The valid data range: 01 – 64.
Refer to Using Sub-locations to see how to scroll from one sub-location to another using the [*] key.
LOCATION 243 View Keypad ID
View the data in this location to determine the Keypad ID (1 – 8).
[INSTALLER CODE] [*] [2] [4] [3] [*]
NOTE: This is a read-only location and no data no can be changed.
LOCATIONS 251 - 258 Keypad Options
These locations are used to configure options for a keypad. Refer to Table 28 for the available
options.
Each location represents a keypad:
 Location 251 is keypad 1
 Location 252 is keypad 2
 Location 253 is keypad 3
 Location 254 is keypad 4
 Location 255 is keypad 5
 Location 256 is keypad 6
 Location 257 is keypad 7
 Location 258 is keypad 8

Table 28: Keypad Options Data
LED
Default
Action
1
ON
The keypad will timeout back to its default partition after it has been used to view
another partition
2
OFF
Keypad sleep mode disabled
3
OFF
Global Keypad Status
4
OFF
Display all of Zones from all Partitions
5
OFF
Shows all Partitions on key press 1,5 & 6
6
OFF
Stay Profile Menu
On = Enable Off = Disable
 LED 3 must be ON in order for LED 1 to have any effect.
 The Global Keypad Status will allow sixteen zones to be displayed regardless of the partition to which
either the keypad or zones are assigned.
On a LED keypad from the keypad start zone number plus 16 zones.
On a LCD keypad from the keypad start zone number up to 64 zones.
