IDS X Series Installer Manual

IDS X-Series Installer Manual 700-398-02H Issued July 2013
52
Enter a 2-digit reporting code for each of the 16 users and program as a 32-digit string, followed by
the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [USER] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if enabled at 0
Refer to Using Sub-locations to see how to scroll through sub-location using the [*] ke1y.
NOTE: The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
LOCATIONS 350 – 357 Stay Close Reporting Code
The 2-digit stay close code is reported when the panel is STAY ARMED. This location is configured per user.
Refer to the User Manual where option 2 of User Reporting Codes Enabled, needs to be enabled.
Each location represents a set of 16 users:
 Location 350 are users 1-16
 Location 351 are users 17-32
 Location 352 are users 33-48
 Location 353 are users 39-64
 Location 354 are users 65-80
 Location 355 are users 81-96
 Location 356 are users 97-112
 Location 357 are users 113-128
Enter a 2-digit reporting code for each of the 16 users and program as a 32-digit string, followed by
the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [USER] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if enabled at 0
Refer to section 0 Using Sub-locations to see how to scroll through sub-location using the [*] key.
NOTE: The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
LOCATIONS 358 – 365 Open Reporting Code
The 2-digit open code is reported when the panel is DISARMED. This location is configured per user. Refer to
the User Manual where option 3 of User Reporting Codes Enabled, needs to be enabled.
Each location represents a set of 16 users:
 Location 358 are users 1-16
 Location 359 are users 17-32
 Location 360 are users 33-48
 Location 361 are users 39-64
 Location 362 are users 65-80
 Location 363 are users 81-96
 Location 364 are users 97-112
 Location 365 are users 113-128
Enter a 2-digit reporting code for each of the 16 users and program as a 32-digit string, followed by
the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [USER] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if enabled
Refer to section 0 Using Sub-locations to see how to scroll from one sub-location to another using the [*] key.
NOTE: The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
LOCATIONS 366 – 373 Siren Cancel Reporting Codes
The 2-digit siren cancel code is reported when the siren is CANCELLED. This location is configured per user.
Refer to the User Manual where option 4 of User Reporting Codes Enabled, needs to be enabled.
Each location represents a set of 16 users:
 Location 366 are users 1-16
 Location 367 are users 17-32
 Location 368 are users 33-48
 Location 369 are users 39-64
 Location 370 are users 65-80
 Location 371 are users 81-96
 Location 372 are users 97-112
 Location 373 are users 113-128
Enter a 2-digit reporting code for each of the 16 users and program as a 32-digit string, followed by
the [*] key.

IDS X Series Specifications

General

Key Type	Tactile
Backlight	Yes
Operating Voltage	12VDC
Weight	150g
Operating Temperature	-10°C to +55°C
