PPC-5190 Flat Panel PC
Page 142
Model PPC-3708GS PPC-3710GS PPC-3712GS PPC-3715GS PPC-3717GS
LCD Size 8.4” TFT LCD 10.4” TFT LCD 12.1” TFT LCD 15” TFT LCD 17” TFT LCD
Max. Resolution 800 x 600 800 x 600 800 x 600 1024 x 786 1280 x 1024
Brightness 220 cd/m2 230 cd/m2 400 cd/m2 350 cd/m2 300 cd/m2
LCD Color 262K 262K 262K 262K 16.2M
Viewing Angle 120/100 120/100 140/110 120/100 140/130
Backlight MTBF 20000hrs 50000hrs 50000hrs 50000hrs 50000hrs
SBC Model NANO-8522
(Socket 479/
BGA On-board)
NANO-8522
(Socket 479/
BGA On-board)
NANO-8522
(Socket 479/
BGA On-board)
ENANO-6612
(Socket 479/
BGA On-board)
ENANO-6612
(Socket 479/
BGA On-board)
CPU Pentium® M /
Celeron® M /
ULV Celeron®
M
1GHz/800MHz
Pentium® M /
Celeron® M /
ULV Celeron®
M
1GHz/800MHz
Pentium® M /
Celeron® M /
ULV Celeron®
M
1GHz/800MHz
Pentium® M /
Celeron® M /
ULV Celeron®
M 1GHz
Pentium® M /
Celeron® M /
ULV Celeron®
M 1GHz
RAM 1 x DDR
266/200MHz
SO DIMM
socket
up to 1GB
1 x DDR
266/200MHz
SO DIMM
socket
up to 1GB
1 x DDR
266/200MHz
SO DIMM
socket
up to 1GB
1 x DDR
333/400MHz
SO DIMM
socket
up to 1GB
1 x DDR
333/400MHz
SO DIMM
socket
up to 1GB
I/O Ports 1 x RS-232/
422/485
1 x RS-232/
422/485
1 x RS-232/
422/485
1 x RS-232/
422/485
1 x RS-232/
422/485
2 x RS-232 2 x RS-232 3 x RS-232 1 x RS-232 1 x RS-232
4 x USB 2.0 4 x USB 2.0 4 x USB 2.0 4 x USB 2.0 4 x USB 2.0
1 x PS/2 1 x PS/2 1 x PS/2 1 x PS/2 1 x PS/2
N/A N/A 1 x LPT 1 x LPT 1 x LPT
1 x VGA out 1 x VGA out 1 x VGA out 1 x VGA out 1 x VGA out
1 x LAN 1 x LAN 1 x LAN 1 x LAN 1 x LAN
3 x Audio 3 x Audio 3 x Audio 3 x Audio 3 x Audio
1 x IDE 1 x IDE 1 x IDE 1 x IDE 1 x IDE
2 x SATA 2 x SATA 2 x SATA 2 x SATA 2 x SATA
SSD CF Type II CF Type II CF Type II CF Type II CF Type II
Expansion Slot N/A N/A N/A 1 x PCI 1 x PCI
HDD Drive Bay 1 x 2.5” 1 x 2.5” 1 x 2.5” 1 x 3.5” 1 x 3.5”
To Next Page
