PPC-5190 Flat Panel PC
Page 164
FAN2: System Fan Connector
PIN Description
1 GND
2 +12V
3 Fan Sensor
FAN3: System Fan Connector
PIN Description
1 GND
2 +12V
3 Fan Sensor
B.12 Inverter (LCD Backlight) Connector
CN12: Inverter (LCD Backlight) Connector
PIN Description PIN Description
1 NC 2 GND
3 +12V 4 GND
5 ENABKL
