IEI Technology PPC-5190GS User Manual

PPC-5190 Flat Panel PC
Page 23
Figure 1-2: PPC-5190 Rear View
1.2.4 Top Panel
The top panel has two fan vents, eight mounting clamp slots and three retention screws for
securing the drive bay bracket. The retention screws are circled in Figure 1-3 below.
Figure 1-3: PPC-5190 Top View
1.2.5 PPC-5190 Bottom Panel
The bottom panel shown in Figure 1-4 has the following interfaces:
