PPC-5190 Flat Panel PC
Page 51
JP8 DESCRIPTION
2-3 closed COM2 RI PIN Use RI
1-2 closed COM2 RI PIN Use Voltage
Table 3-7: COM2 RI and Voltage Selection Jumper
JP6 DESCRIPTION
2-3 closed COM2 RI PIN Use Voltage +12V
1-2 closed COM2 RI PIN Use Voltage +5V
Table 3-8: COM2 RI Voltage Selection Jumper
Use JP13 and JP15 to set pin 9 of COM3 as signal RI or voltage source.
JP15 DESCRIPTION
2-3 closed COM3 RI PIN Use RI
1-2 closed COM3 RI PIN Use Voltage
Table 3-9: COM3 RI and Voltage Selection Jumper
JP13 DESCRIPTION
2-3 closed COM3 RI PIN Use Voltage +12V
1-2 closed COM3 RI PIN Use Voltage +5V
Table 3-10: COM3 RI Voltage Selection Jumper
Use JP14 and JP16 to set pin 9 of COM4 as signal RI or voltage source.
JP16 DESCRIPTION
2-3 closed COM4 RI PIN Use RI
1-2 closed COM4 RI PIN Use Voltage
Table 3-11: COM4 RI and Voltage Selection Jumper
