PPC-5190 Flat Panel PC
Page 31
WARNING:
Under no circumstances is the PSU case to be opened. The PSU
module is not user serviceable and there are dangerous high-voltages
inside the case. If there are any problems with the PSU module, please
contact the dealer or reseller immediately.
1.4.5.1 ACE-4518AP Power Supply
Specifications for the ACE-4518AP PSU module are shown in (Table 1-5).
Voltage AC90V ~ 265VAC Full Range
Frequency 47 ~ 63Hz
Input Current 4A(RMS)@115VAC
2A(RMS)@230VAC
INPUT
Inrush Current 50A Max for 115VAC
80A Max for 230VAC
Voltage (V) +3.3V +5V +12V -12V 5VSB
Min. Load (A) 0.3A 0.3A 1.5A 0A 0A
Max. Load (A) 16.8A 12A 10A 0.8A 2A
Ripple and Noise (mV) 50mV 50mV 120mV 120mV 50mV
OUTPUT
+3.3V & +5V≦61W
+3.3V & +5V & +12V≦160W
Watt 180W
PFC Active
Hold-up time 17ms minimum
Efficiency 68%
GENERAL
MTBF 100,000hrs
To Next Page
