PPC-5190 Flat Panel PC
Page 30
Size 19”
Resolution SXGA (1280 x 1024)
Active Area (mm) 376.32 x 301.06
Pixel Pitch (mm) 0.294
Mode TN
Number of Colors 16.2M
Color Saturation (%) 72
View Angel (H/V) 160 / 160
Brightness (cd/m2) 300
Contrast Ratio 700 : 1
Response Time (ms) (at 25°C) 6
Power Consumption (W) 28
Interface 2ch LVDS
Supply Voltage (V) 5
Backlight 4 CCFL
Outline Dimensions (mm) 396.0 x 324.0 x 17.5
Weight (g) 2500
Table 1-4: 19” TFT LCD Monitor Specifications
1.4.5 Power Supply
The PPC-5190 flat panel PC comes with either an ACE-4518AP 180W AC-DC 1U, or
ACE-4520C 200W DC 1U RoHS compliant ATX power supply. The PSUs have an MTBF
greater than 100,000 hours.
