IEI Technology PPC-5190GS User Manual

PPC-5190 Flat Panel PC
Page 151
B.2 PCIe - IDE Disk Drive Connector
Four IDE (Integrated Device Electronics) hard disk drives can be attached to the
POS-8520 IDE controller.
IDE1, IDE2: Primary, Secondary IDE Connector
PIN Description PIN Description
1 RESET# 2 GND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GND 20 N/C
21 IDE DRQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 IDE CHRDY 28 GND
29 IDE DACK 30 GND
31 INTERRUPT 32 N/C
33 SA 1 34 N/C
35 SA 0 36 SA 2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GND
