B.7 USB Port Connector

The POS-8520 has eight built-in USB ports for the future I/O bus expansion.

CN26, CN27, CN28: 8-PIN Header USB Connectors

PIN Description

1 8 VCC

3 6 USBD0-

5 4 USBD0+

7 2 GND

CN25: 2 External USB Connectors

PIN Description

1 5 VCC

2 6 USBD0-

3 7 USBD0+

4 8 GND
