PPC-5190 Flat Panel PC

Page 166

CN2: Audio LINE OUT (2.54mm)

PIN Description PIN Description

1 LINEOUT_L 2 GND

3 GND 4 LINE OUT_R

CN24: Audio Jack

Color Description

RED MIC IN

BLUE LINE IN

GREEN SPEAK OUT

B.15 Digital Input / Output

CN6: Digital Input / Output

PIN Description PIN Description

1 GND 2 +5V

3 Output 3 4 Output 2

5 Output 1 6 Output 0

7 Input 3 8 Input 2

9 Input 1 10 Input 0
