PPC-5190 Flat Panel PC
Page 32
Temperature 0~50°C (Operating)
-20~80°C (Storage)
Humidity 5 –95% RH, Non-condensing
(Operating & Storage)
Dimension 150mm (W) x 81.5mm (H) x 40.5mm (D)
Table 1-5: ACE-4518AP Power Supply Specifications
1.4.5.2 ACE-4520C Power Supply
Specifications for the ACE-4520C PSU module are shown in (Table 1-6).
Voltage 18VDC ~ 36VDC Full Range
Input Current 15A
INPUT
Inrush Current 100A
Voltage (V) +3.3V +5V +12V -12V 5VSB
Min. Load (A) 0.0A 1.0A 0.5A 0.0A 0.0A
Max. Load (A) 12A 12A 15.4A 0.5A 2.0A
Ripple and Noise (mV) 50mV 50mV 120mV 120mV 50mV
OUTPUT
+3.3V & +5V≦80W; +3.3V & +5V & +12V≦184W
Watt 200W
PFC Active
Hold-up time 20ms minimum
Efficiency 78%
MTBF 100,000hrs
Temperature 0~50°C (Operating); -20~80°C (Storage)
Humidity 5 –95% RH, Non-condensing (Operating & Storage)
GENERAL
Dimension 150mm (W) x 81.5mm (H) x 40.3mm (D)
Table 1-6: ACE-4520C Power Supply Specifications
