PPC-5190 Flat Panel PC
Page 146
Model PPC-5150GS PPC-5170GS PPC-5190GS
3 x RS-232 3 x RS-232 3 x RS-232
4 x USB 2.0 6 x USB 2.0 6 x USB 2.0
2 x PS/2 2 x PS/2 2 x PS/2
1 x LPT 1 x LPT 1 x LPT
1 x VGA out 1 x VGA out 1 x VGA out
2 x LAN 2 x LAN 2 x LAN
3 x Audio 3 x Audio 3 x Audio
2 x IDE 2 x IDE 2 x IDE
2 x SATA 2 x SATA 2 x SATA
SSD CF Type II CF Type II CF Type II
Expansion Slot 1 x PCI, 1 x PCIe 1 x PCI, 1 x PCIe 1 x PCI, 1 x PCIe
HDD Drive Bay 2 x 3.5” SATA/IDE HDD
w/ Anti-Shock
2 x 3.5” SATA/IDE HDD
w/ Anti-Shock
2 x 3.5” SATA/IDE HDD
w/ Anti-Shock
FDD Drive Bay 1 x Slim FDD 1 x Slim FDD 1 x Slim FDD
CD-ROM
Drive Bay
1 x Slim CD-ROM 1 x Slim CD-ROM 1 x Slim CD-ROM
Power Supply 250W ATX Power 250W ATX Power 250W ATX Power
Mounting Stand/Rack/
Wall/Panel/Arm
Stand/Rack/
Wall/Panel/Arm
Stand/Rack/
Wall/Panel/Arm
Dimension
(WxDxH) mm
TBD TBD TBD
Weight TBD TBD TBD
Front Panel
Protection
IP 65 compliant IP 65 compliant IP 65 compliant
Touch Screen Resistive Type 5-wire
with RS-232 Interface
Resistive Type 5-wire
with RS-232 Interface
Resistive Type 5-wire
with RS-232 Interface
Table A-4: PPC-52 Series Panel PC Solutions
A.2.5 PPC-53 Series Panel PC Solutions
All the models listed in the table below support Intel
®
Pentium® M / Celeron ® M /
ULV Celeron® M 1GHz/800MHz CPUs.
