PPC-5190 Flat Panel PC
Page 29
Southbridge ICH5
Max. FSB 533 MHz
Memory 2 x DDR 266/333 DIMM socket up to 2GB
BIOS AMI BIOS Label
CRT integrated in Intel 852GME
Display
LVDS Dual 18-bit TTL LCD integrated in Intel 852GM
Expansion Interface
1 x PCI slot
1 x CFII
Audio AC' 97 Codec
Ethernet 2 x Realtek RTL8110SC GbE controller
COM
1 x RS-232/422/485 port
5 x RS-232 ports (1 for optional touch screen)
USB 2.0 6 x USB 2.0 ports
Drive Interfaces 2 x SATA drive connectors
LPT 2 x ATA 100 channels
KB/ MS 2 x PS/2 connector
IrDA 1 x IrDA interface
Table 1-3: Motherboard Specifications
1.4.4 Flat Panel Screen
The PPC-5190 comes with a 19” TFT LCD monitor at the front of the flat panel PC
(Figure 1-1). The specifications for the LCD monitor are shown in Table 1-4 below.
SPECIFICATION DESCRIPTION
Model AUO-M190EG02
