PPC-5190 Flat Panel PC
Page 152
B.3 Parallel Port
This port is usually connected to printer. The POS-8520 includes one on-board parallel
port, accessed through 25-pin D-type female connector LPT1.
LPT1: (LPT1 DB-25 Female) Parallel Port Connector
PIN Description PIN Description
1 STROBE# 2 DATA 0
3 DATA 1 4 DATA 2
5 DATA 3 6 DATA 4
7 DATA 5 8 DATA 6
9 DATA 7 10 ACKNOWLEDGE
11 BUSY 12 PAPER EMPTY
13 PRINTER SELECT 14 AUTO FORM FEED #
15 ERROR# 16 INITIALIZE
17 PRINTER SELECT LN# 18 GND
19 GND 20 GND
21 GND 22 GND
23 GND 24 GND
25 GND
