PPC-5190 Flat Panel PC
Page 141
Model PPC-2706GS PPC-2708GS
Viewing Angle 120/100 120/100
Backlight MTBF 50000hrs 20000hrs
SBC Model WAFER-LX800 WAFER-LX800
CPU AMD LX800 AMD LX800
RAM 1 x DDR 333/400MHz
SO DIMM socket up to
1GB
1 x DDR 333/400MHz
SO DIMM socket up to 1GB
I/O Ports 1 x RS-232 2 x RS-232
2 x USB 2.0 2 x USB 2.0
1 x PS/2 1 x PS/2
1 x VGA out 1 x VGA out
2 x LAN 2 x LAN
1 x Audio 3 x Audio
1 x IDE 1 x IDE
2 x SATA 2 x SATA
SSD CF Type II CF Type II
HDD Drive Bay 1 x 2.5” SATA/IDE HDD 1 x 2.5” SATA/IDE HDD
Power Supply 60W AC Adapter 60W AC Adapter
Mounting Stand/Rack/Wall/
Panel/Arm/Din
Stand/Rack/Wall/
Panel/Arm/Din
Dimension (WxDxH)
mm
183 x 143 x 62.6 244 x 178 x 67
Weight 1.4/3.4kg 2.2/4.4kg
Front Panel Protection IP 65 compliant IP 65 compliant
Touch Screen Resistive Type 4-wire
with RS-232 Interface
Resistive Type 4-wire
with RS-232 Interface
Table A-1: PPC-27 Series Panel PC Solutions
A.2.2 PPC-37 Series Panel PC Solutions
All the models listed in the table below support Intel
®
Pentium® M / Celeron ® M /
ULV Celeron® M 1GHz/800MHz CPUs.
