PPC-5190 Flat Panel PC
Page 162
B.9 VGA Connector
The POS-8520 provides one DB-15 female connector and one built-in 10-pin VGA box
header connector that can be connected directly to a monochrome CRT monitor as well as
high resolution color CRT monitor.
VGA1: DB-15 Female VGA Connector
PIN Description PIN Description
1 RED 2 GREEN
3 BLUE 4 N/C
5 GND 6 GND
7 GND 8 GND
9 VCC 10 GND
11 N/C 12 DDC DAT
13 HSYNC 14 VSYNC
15 DDC CLK
CN14: 10-pin Header VGA Connector
PIN Description PIN Description
1 RED 2 SMCLK
3 GREEN 4 SMDATA
5 BLUE 6 GND
7 H-SYNC 8 GND
9 V-SYNC 10 GND
