PPC-5190 Flat Panel PC

Page 159

CN15: PS/2 Mouse 5-pin Header Connector

PIN Description

1 MS CLOCK

2 MS DATA

3 N/C

4 GND

5 +5V

B.6 External Switches and Indicators

CN8: Multi Panel

PIN Description PIN Description

1 SPEAKER 11 POWER-VCC

2 N/C 12 N/C

3 N/C 13 GND

4 +5V 14 KEYLOCK

5 RESET SW 15 GND

6 GND 16 GND

7 IDE LED - 17 N/C

8 IDE LED+ 18 ATX POWER CONTROL

9 ATX POWER BUTTON 19 ATX 5VSB

10 GND 20 ATX 5VSB
