3.25 ASSEMBLY OF MANIFOLD GASKET ON CONDENSATION MODULE
e operations described below must be performed aer having removed the voltage from the
appliance.
If the gasket has to be replaced, proceed as follows:
1. Remove the old gasket.
2. Place the module gasket (1) radially on the edge of the condensation module ange (2).
3. Make sure that the gasket tab with number 4 printed on it is positioned in its seat on the module ange, identied by the number 4.
Every time the manifold is opened, the condition and integrity of the ceramic bres must be veried and re-
placed, if necessary. e manifold gasket, on the other hand, must be replaced every 2 years. Aer replacing the
external silicone gasket, it is mandatory to check the fume tightness.
1
2
