1.15 INTERNAL INSTALLATION USING A RECESSED FRAME WITH DIRECT AIR INTAKE
Conguration type B, open chamber and fan assisted
In this conguration the appliance is classied as type B
23
.
Using a kit separator, one can achieve direct air intake (Fig. 15) and ue exhaust in a single chimney or directly outside.
With this conguration:
- air intake takes place directly from the environment in which the appliance is installed and only functions in permanently ventilated
rooms;
- the ue gas exhaust must be connected to its own individual chimney and channelled directly into the external atmosphere.
e technical regulations in force must be respected.
15
Separator kit installation (Fig. 16).
1. Install the discharge ange on the middle hole of the appliance, positioning the relative gasket with the circular projections down-
wards in contact with the appliance ange, and tighten using the hex screws with at tip contained in the kit.
2. Remove the at ange present in the lateral hole with respect to the central one (according to needs) and replace it with the intake
ange, positioning its gasket and tighten using the supplied self-threading screws.
3. Fit the curves with the male side (smooth) into the female side of the anges (the intake curve must face the rear side of appliance).
4. Fit the exhaust pipe with the male side (smooth) to the female side of the bend up to the end stop, making sure that the internal wall
sealing plate has been tted and connecting the required ue according to personal requirements.
16
In case of installation C
(10)
/C
(12)
the ue gas non-return valve must be installed and ONLY the vertical outlet can be installed in the re-
cessed frame.
