Immergas VICTRIX EXTRA 12 PLUS - Removable Memory

85
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
3.6 REMOVABLE MEMORY
Replacing the memory must be carried out aer disconnecting all electrical connection of the
P.C .B.
P.C.B.
e P.C.B. is equipped with a removable memory (Ref. 2 Fig.54) which records all operation parameters and appliance customisations.
Should the P.C.B. be replaced, you can use the memory of the replaced board again, so it is not necessary to recongure the appliance.
1
2
54
Key (Fig. 54):
1 - Quick fuse 3.15 250 V Type F
2 - Grey removable memory (A19)
