4.2 COMBUSTION PARAMETERS
Combustion parameters: measuring conditions of useful eciency (ow temperature/return temperature= 80/60 °C), ambient temper-
ature reference = 20 °C.
Victrix Extra 12 Plus
Gas type G20 G31
Supply pressure mbar 20 37
Gas nozzle diameter mm 5,7 5,7
Ignition fan speed rpm 3800 3800
Flue ow rate at heating nominal heat output kg/h 20 21
Flue ow rate at min heat output kg/h 3 4
CO
2
at Nominal Q.
O
2
at Nominal Q.
%
8,8 (8,3 ÷ 9,3)
5,1 (6,0 ÷ 4,2)
10,0 (9,5 ÷ 10,5)
- (- ÷ -)
CO
2
at Minimum Q.
O
2
at Minimum Q.
%
8,8 (8,3 ÷ 9,3)
5,1 (6,0 ÷ 4,2)
9,5 (9,0 ÷ 10,0)
- (- ÷ -)
CO with 0% O
2
at Nom./Min. Q. ppm 45 / 1 57 / 6
NO
x
with 0% O
2
at Nom./Min. Q. mg/kWh 30,0 / 16,0 38,0 / 24,0
Flue temperature at nominal output °C 62 58
Flue temperature at minimum output °C 58 57
When using H2NG mixtures with H
2
percentages up to 20% (referring to the gas distributed in the network), all calibration operations of
the device must refer to the O
2
values of the G20 gas given in the following table.
Intake / exhaust available head F0 = 0 Intake / exhaust available head F0 = 1 Intake / exhaust available head F0 = 2
Pa Pa Pa
6 20 32
Victrix Extra 24 Plus
Gas type G20 G31
Supply pressure mbar 20 37
Gas nozzle diameter mm 5,7 5,7
Ignition fan speed rpm 3800 3800
Flue ow rate at heating nominal heat output kg/h 41 42
Flue ow rate at min heat output kg/h 5 5
CO
2
at Nominal Q.
O
2
at Nominal Q.
%
8,8 (8,3 ÷ 9,3)
5,1 (6,0 ÷ 4,2)
10,0 (9,5 ÷ 10,5)
- (- ÷ -)
CO
2
at Minimum Q.
O
2
at Minimum Q.
%
8,8 (8,3 ÷ 9,3)
5,1 (6,0 ÷ 4,2)
9,5 (9,0 ÷ 10,0)
- (- ÷ -)
CO with 0% O
2
at Nom./Min. Q. ppm 154 / 4 181 / 5
NO
x
with 0% O
2
at Nom./Min. Q. mg/kWh 21,0 / 17,0 22,0 / 23,0
Flue temperature at nominal output °C 70 67
Flue temperature at minimum output °C 60 58
When using H2NG mixtures with H
2
percentages up to 20% (referring to the gas distributed in the network), all calibration operations of
the device must refer to the O
2
values of the G20 gas given in the following table.
Intake / exhaust available head F0 = 0 Intake / exhaust available head F0 = 1 Intake / exhaust available head F0 = 2
Pa Pa Pa
36 110 178
