1.14 OUTDOOR INSTALLATION IN PARTIALLY PROTECTED AREA
By partially protected area, we mean one in which the unit is not directly exposed to the elements (rain, snow, hail, etc.).
If the appliance is installed in a location where the ambient temperature falls below -5°C, use the optional antifreeze kit, check-
ing the ambient temperature range for operation in the technical data table in this instruction manual (Section 'Technical
Data').
is type of installation is possible when permitted by the laws in force in the appliance's country of destination.
Conguration type B, open chamber and fan assisted (B
23
or B
53
).
Using the relevant cover kit, direct air intake is possible and ue gas is exhausted into a single ue or directly to the outside. In this cong-
uration it is possible to install the appliance in a partially protected place. In this conguration the appliance is classied as type B.
With this conguration:
- the ue gas exhaust must be connected to its own single chimney (B
23
) or ducted directly outside via a vertical terminal for direct ex-
haust (B
53
) or via an Immergas ducting system (B
53
).
e technical regulations in force must be respected.
Cover kit assembly (Fig.14).
Remove the two plugs from the two lateral intake holes.
Install the Ø 80 outlet ange on the central hole of the boiler, taking care to insert the gasket supplied with the kit and tighten by means of
the screws provided.
Install the upper cover, xing it using the 4 screws present in the kit, positioning the relevant gaskets.
Engage the 90° Ø 80 bend with the male end (smooth) in the female end (with lip seal) of the Ø 80 ange unit to the end stop. Introduce the
gasket, making it run along the bend. Fix it using the metal sheet plate and tighten by means of the clips present in the kit, making sure to
block the 4 gasket aps.
Fit the male end (smooth) of the exhaust pipe into the female end of the 90° Ø 80 bend, making sure that the relevant wall sealing plate is
already tted; this will ensure hold and joining of the elements making up the kit.
Max. length of exhaust duct.
e ue pipe (both vertical or horizontal) can be extended to a max. length of 30 linear metres.
Coupling of extension pipes.
To install push-tting extensions with other elements of the ue, proceed as follows: Couple the pipe or elbow with the male side (smooth)
in the female side (with lip seal) to the end stop on the previously installed element. is will ensure sealing eciency of the coupling.
Conguration without cover kit in a partially protected location (type C appliance).
By leaving the side plugs tted, it is possible to install the appliance externally, in a partially covered place, without the cover kit.
Installation takes place using the Ø 60/100 and Ø 80/125 concentric intake/ exhaust kits. Refer to the paragraph on indoor installation.
e top cover kit, which provides additional protection for the boiler, CANNOT be used with Ø 80/80 separator conguration,
Ø 60/100 concentric and Ø 80/125.
