1.18 SEPARATOR KIT INSTALLATION
Type C conguration, sealed chamber and fan assisted separator kit Ø 80/80
is kit allows air to come in from outside the building and the exhaust to exit from the chimney, ue or intubated duct through divided
ue exhaust and air intake pipes.
Combustion products are expelled from pipe (S) (in plastic, so as to resist acid condensate).
Air is taken in through duct (A) for combustion (this is also in plastic).
e intake pipe (A) can be installed either on the right or le hand side of the central exhaust pipe (S).
Both ducts can be routed in any direction.
Assembly of separator kit Ø 80/80 (Fig. 25):
1. Install the ange (4) on the central hole of the appliance, positioning gasket (1) with the circular projections downwards in contact
with the appliance ange.
2. Tighten with the hexagonal head and at point screws provided in the kit.
3. Replace the at ange present in the lateral hole with respect to the central one (according to needs) with the ange (3), positioning the
gasket (2) in between.
4. Tighten with the supplied self-tapping screws with drill bit.
5. Fit the bends with male side (smooth) (5) in the female side of the anges (3 and 4).
6. Fit the intake terminal (6) with the male side (smooth) in the female side of the bend (5) up to the end stop, ensuring that the internal
and external wall sealing plates are tted
7. Fit the exhaust pipe (9) with the male end (smooth) to the female end of the bend (5) up to the end stop; making sure that the internal
wall sealing plate has been tted, this will ensure sealing and joining of the elements making up the kit.
C
53
* - C
83
1
4
7
9
5
5
6
7
8
3
2
S
A
25
e kit includes (Fig. 25):
N°1 Exhaust gasket (1)
N°1 Flange gasket (2)
N°1 Female intake ange (3)
N°1 Female exhaust ange (4)
N°2 Ø 80 90° bend (5)
N°1 Intake terminal Ø 80 (6)
N°2 Internal wall sealing plates (7)
N°1 External wall sealing plate (8)
N°1 Exhaust pipe Ø 80 (9)
* to complete C
53
conguration, also provide for a "green range" roof
discharge terminal. e conguration on walls opposite the build-
ing is not allowed.
