2.6 INFORMATION MENU
Press the "INFO" button (pos. 3, Fig. 48) for at least 1 second for the "Information menu" to open, displaying some boiler operation param-
eters.
To scroll through the various parameters, press the "INFO" button (pos. 3, Fig. 48). en press 'MODE' to display the value.
To go back to the previous screen or exit the menu, press "RESET" (pos. 4, Fig. 48), or wait 15 minutes.
Parameter ID Description
d.0 Not used
d.1 Displays the ame signal
d.2 Displays the primary heat exchanger outlet instant CH ow temperature (°C)
d.3 Displays the temperature of the storage tank unit (°C) (when paired to a storage tank unit)
d.4 Displays the values set for central heating set
d.5 Displays the set value for the DHW set (when paired with a storage tank unit)
d.6
Displays the external environment temperature (°C) (if optional external probe present). If the temperature is below zero, the
value is displayed ashing.
d.7 Not used
d.8 Displays the system return water temperature (°C)
d.9 Displays the list of the last 5 faults (to scroll the list press the "central heating temperature regulation" buttons +/- (7-8))
d.10
Anomaly list reset. Once "d.10" is displayed, press MODE; the display shows "--". en press MODE again for at least 3 seconds;
deletion is conrmed via the "88 88" symbols ashing for two seconds.
d.11 Not used
d.12 Displays the pump operating speed
d.13 Not used
d.14 Displays the pump ow rate (l/h)
d.15 Displays the fan operating speed (rpm)
d.16 Displays the temperature read on the ue probe (°C)
d.17 Displays the calculated ow temperature (°C)
d.18 At the end of the screed heater function, displays for how many hours the ow temperature remained at “Top set”
d.19 Displays alternately safety soware version, functional soware version and MMI display version
d.20 Displays the ow temperature of zone two (°C) (optional)
d.21 Displays the ow temperature of zone three (°C) (optional)
d.22 Not used
d.23 DHW gas valve operation hours (x10)
d.24 C.H. gas valve operation hours (x10)
d.25 Ignition cycle number (x10)
d.26 Not used
d.27 Not used
