36
INSTALLERUSERMAINTENANCE TECHNICIANTECHNICAL DATA
1.17 CONCENTRIC VERTICAL KIT INSTALLATION
Type C conguration, sealed chamber and fan assisted
Concentric vertical intake and exhaust kit.
is vertical terminal is connected directly to the outside of the building for air intake and ue gas exhaust.
e vertical kit with aluminium slate enables installation on terraces and roofs with a maximum slope of 45% (approx 25°) and
the height between the terminal cap and half-shell (374 mm for Ø 60/100 and 260 mm for Ø 80/125) must always be observed.
Vertical kit assembly with aluminium slate Ø60/100 (Fig. 21)
1. Install the concentric ange (2) on the ue exhaust of the appliance, positioning gasket (1) with the circular projections downwards in
contact with the appliance ange.
2. Tighten the concentric ange with the screws in the kit.
Imitation aluminium slate installation:
3. Replace the slates with the aluminium sheet (4), shaping it to ensure that rainwater runs o.
4. Position the xed half-shell (6) on the aluminium slate.
5. Insert the intake-exhaust pipe (5).
6. Fit the Ø 60/100 concentric terminal pipe with the male side (5) (smooth) into the ange (2) up to the end stop, making sure that the
wall sealing plate has been tted (3); this will ensure sealing and joining of the elements making up the kit.
When the appliance is installed in areas where very rigid temperatures can be reached, a special anti-freeze kit is available that
can be installed as an alternative to the standard kit.
C
33
7
4
6
5
1
2
3
21
e kit includes (Fig. 21):
N° 1 Gas ket (1)
N°1 Female concentric ange (2)
N°1 Wall sealing plate (3)
N°1 Aluminium slate (4)
N°1 Concentric intake/exhaust pipe Ø 60/100 (5)
N°1 Fixed half-shell (6)
N°1 Mobile half-shell (7)
