TECHNICAL DATA
Extensions for Ø 60/100 vertical kit (Fig. 22)
e kit with this conguration can be extended up to a maximum
of 14.4 m vertical straight, including the terminal; this congura-
tion corresponds to a resistance factor of 100. In this case specic
coupling extensions must be requested.
