TECHNICAL DATA
Victrix Extra 35 Plus
Gas type G20 G31
Supply pressure mbar 20 37
Gas nozzle diameter mm 5,7 5,7
Ignition fan speed rpm 3800 3800
Flue ow rate at heating nominal heat output kg/h 55 55
Flue ow rate at min heat output kg/h 5 5
CO
2
at Nominal Q.
O
2
at Nominal Q.
%
8,8 (8,3 ÷ 9,3)
5,1 (6,0 ÷ 4,2)
10,0 (9,5 ÷ 10,5)
- (- ÷ -)
CO
2
at Minimum Q.
O
2
at Minimum Q.
%
8,8 (8,3 ÷ 9,3)
5,1 (6,0 ÷ 4,2)
9,5 (9,0 ÷ 10,0)
- (- ÷ -)
CO with 0% O
2
at Nom./Min. Q. ppm 168 / 4 197 / 3
NO
x
with 0% O
2
at Nom./Min. Q. mg/kWh 30,0 / 19,0 32,0 / 18,0
Flue temperature at nominal output °C 78 77
Flue temperature at minimum output °C 56 53
When using H2NG mixtures with H
2
percentages up to 20% (referring to the gas distributed in the network), all calibration operations of
the device must refer to the O
2
values of the G20 gas given in the following table.
Intake / exhaust available head F0 = 0 Intake / exhaust available head F0 = 1 Intake / exhaust available head F0 = 2
Pa Pa Pa
49 152 247
