TECHNICAL DATA
Victrix Extra 12 Plus
Gas type CO
2
to nominal Q. CO
2
to ignition Q. CO
2
to minimum Q.
G20 8,8 (8,3 ÷ 9,3) % 8,8 (8,3 ÷ 9,3) % 8,8 (8,3 ÷ 9,3) %
G31 10,0 (9,5 ÷ 10,5) % 10,0 (9,5 ÷ 10,5) % 9,5 (9,0 ÷ 10,0) %
Gas type O
2
at Nominal Q. O
2
at Ignition Q. O
2
at Minimum Q.
G20 5,1 (6,0 ÷ 4,2) % 5,1 (6,0 ÷ 4,2) % 5,1 (6,0 ÷ 4,2) %
Victrix Extra 24 Plus
Gas type CO
2
to nominal Q. CO
2
to ignition Q. CO
2
to minimum Q.
G20 8,8 (8,3 ÷ 9,3) % 8,8 (8,3 ÷ 9,3) % 8,8 (8,3 ÷ 9,3) %
G31 10,0 (9,5 ÷ 10,5) % 10,0 (9,5 ÷ 10,5) % 9,5 (9,0 ÷ 10,0) %
Gas type O
2
at Nominal Q. O
2
at Ignition Q. O
2
at Minimum Q.
G20 5,1 (6,0 ÷ 4,2) % 5,1 (6,0 ÷ 4,2) % 5,1 (6,0 ÷ 4,2) %
Victrix Extra 35 Plus
Gas type CO
2
to nominal Q. CO
2
to ignition Q. CO
2
to minimum Q.
G20 8,8 (8,3 ÷ 9,3) % 8,8 (8,3 ÷ 9,3) % 8,8 (8,3 ÷ 9,3) %
G31 10,0 (9,5 ÷ 10,5) % 10,0 (9,5 ÷ 10,5) % 9,5 (9,0 ÷ 10,0) %
Gas type O
2
at Nominal Q. O
2
at Ignition Q. O
2
at Minimum Q.
G20 5,1 (6,0 ÷ 4,2) % 5,1 (6,0 ÷ 4,2) % 5,1 (6,0 ÷ 4,2) %
If a Hydrogen ready installation is planned for H
2
percentages up to 20%, (referring to the gas distributed in the network accord-
ing to local standards in force) all calibration of the unit must refer to the O
2
values in the table above.
In addition to yearly maintenance, one must also check the energy eciency of the thermal system, with frequency and proce-
dures that comply with the indications of the technical regulations in force.
In the setting at Q. Nominal and at Q. Minimum, if the O
2
values are not reached, the Automatic Calibration procedure must be
repeated. If aer this operation the values are still not within the indicated ranges, no further adjustments are necessary.
In the case of an annual inspection of the device, the max CO must be less than 700 ppm (0% O
2
). If the CO value is higher, the
device requires maintenance/repair.
