Interfaces
The thermography system is equipped with the following interfaces:
■ Drive for SD/SDHC card (behind the cover on the left side of the camera. unfold the display)
■ RS232* (LEMO 14-pin)
■ DVI-D (HDMI socket) behind the cover on the backside of the camera, composite video
(LEMO 14-pin)
■ 2 x digital E/A for external trigger input/trigger output* (TTL level, LEMO 14-pin)
■ 2 x analogueue output* 0-5V (LEMO 14-pin)
■ GigE-Vision* (LEMO 8-pin)
■ USB2.0* (mini-AB, behind the cover on the backside of the camera)
■ WLAN* (external antenna*)
■ Bluetooth* (external antenna*)
Simultaneously using several interfaces on the 14-pin LEMO socket is allowed for by means of a
breakout box*. In this case, the breakout box* is also used for external power supply.
As an alternative to the digital high-resolution DVI-D image data on the HDMI socket, the analogue image
data (4:3 PAL/NTSC) is available as FBAS signal (composite) on the 14-pin LEMO socket. The HDMI
socket can be used to connect screens processing a resolution of (1.280 x 768) or (1.280 x 800) in
accordance with the VESA standard.
In connection with the software packages IRBIS
®
3 remote* and IRBIS
®
3 online*, the GigE-Vision
interface* allows for remotely controlling the thermography system, as well as for transmitting digital
image information to a PC in real time*.
