Thermography System VarioCAM
®
HD
3. Introduction
12 © InfraTec GmbH 2016 User Manual
3.3 Technical data
Spectral range (7.5 ... 14) µm
Temperature measuring range (-40 ... 1.200) °C. optionally > 1.200°C
Temperature resolution @ 30°C Better than 0.05 K. optionally 0.03 K according to camera/detector type
Measurement accuracy ± 1.5 K or ± 1.5 %
Emissivity Adjustable between 0.1 and 1.0 in increments of 0.01
Image format (pixels) (1.024 x 768). resolution enhancement to (2.048 x 1.536)
(640 x 480). resolution enhancement to (1.280 x 960)
Detector Uncooled Microbolometer Focal Plane Array
IR frame rate 30Hz (1.024 x 768); 60Hz (640 x 480)
Normal lens (field of view) 1.0/30mm (32.4 x 24.6)° at (1.024 x 768)
1.0/30mm
(29.9 x 22.6)
° at (640 x 480)
Zoom function up to 32-fold digital
A/D conversion 16 bit
Image storage SDHC card. GigE-Vision 30 Hz and/or 60 Hz
Voice recording/text comment Image-integrated
Interfaces DVI-D*. PAL/NTSC-FBAS*. GigE-Vision*. RS232*. USB2.0*. SDHC
card. WLAN*/Bluetooth*. 2 x digital E/A*. 2 x analogue Out*
Integrated digital color video camera 8 Megapixels. LED video light
Power supply Rechargeable lithium-ion battery. wall plug transformer*
Rechargeable battery system Lithium-ion, fast-chargeable, with status display, mains and passenger
vehicle charging adapter
Rechargeable battery-based operation Up to approx. 3 h
Working temperature range (-25 ... 50) °C; activation temperature > -15°C
Storage temperature range (-40 ... 70) °C
Moisture during operation and storage Relative humidity 5% to 95%. non-condensing
Dimensions (with normal lens) (210 x 125 x 155) mm
Weight (with normal lens) 1.7kg
Tripod connection 1/4" photo thread
ttention: observe max penetration depth of 4.5mm!
(DIN 4503)
Display Daylight-compatible, digital 5.6" TFT display with 1280 x 800 pixels
Viewfinder* Swivel-mounted colour viewfinder with (800 x 600) pixels and diopter
compensation
Controls Multi-function joystick, focus rocker switch, up to 10 function buttons
Range finder, laser Semi-conductor laser red, laser protection class 2
Display functions Thermogram, VIS, merge, operator guidance, menu, results, status,
temperature range
Measuring functions Max. 8 freely selectable ROI, auto hot/cold spot display, isotherms
Automatic functions Autofocus, autoimage, autolevel, autorange, alarm*, auto-NUC, auto
lens detection, premium snap*, resolution enhancement*
Degree of protection during operation
IP54, IEC
60529
Impact strength
25 G,
ISO 60068-2-27
Vibration strength during operation
2 G,
ISO 60068-2-27
* (Properties and technical specifications, depend on the camera configuration and vary within the equipment packages of VarioCAM
®
HD,
Design and specification are subject to continuous further development; subject to changes within the meaning of technical progress.)
