8. Introduction
User Manual © InfraTec GmbH 2016 27
Ex factory, the functions are assigned to the function buttons in such a way that functions required very
frequently can be executed quickly:
Button Type Function Explanation
Short Autoimage Automatic adaptation temperature scale
Long NUC Non-uniformity correction (compensation)
Long Menu Level/Range For manually setting Level/Range
Short Spot ON/OFF
If no ROI was created yet create spot 1
Otherwise hide/display ROI
Long Spot editor ROI settings
Short Laser ON/OFF Mark and range finder
Long Max/Min ON/OFF Global max/min measurement On/Off
Short IR VIS Switch-over image mode
Long Color SW For manually setting Max/Min
Halfway LED ON/OFF Photo lamp
Complete FREEZE
Subsequent image saving possible using
The function of the save button
when saving images is defined in the "Image" menu (see chapter
9.2.7 Menu item "Saving format" – page 55).
Furthermore, the save button
can be used in order to immediately accept inputs in many menus. This
function shortens the navigation and is activated ex factory, but can also be deactivated (see chapter
9.4.8 Menu item "System" – page 75).
The multi-function joystick can be used to navigate and to select functions, to input using the arrow
buttons , , , , as well as the function (Enter, push the center).
The focus rocker switch can be used in order to
■ Manually focus the infrared image:
change the focus to longer distance push left
change the focus to shorter distance push right
■ Or to focus automatically:
center function of the focus rocker switch.
The Power button is used to switch on the VarioCAM
®
HD. Initially, the status LED on the left-hand
side above the button will start to flash green and the logo of the camera manufacturer is displayed on
the camera display. Upon successful system initialisation, the status LED will be illuminated permanently
green: the VarioCAM
®
HD is now ready to operate. The system start takes approx. 30 seconds.
Fig. 23 System initialisation indication
In order to switch off the VarioCAM
®
HD, please also use the power button .
