Multi-core crimped cable
Some applications require single cables with crimp terminals. This makes the wiring cleaner and is a
preferred option for volume applications. Pluto connectors include locking latches that provide audible
click during mating and ensure assembly robustness.
Manufacturer Manufacturer ID Farnell Digikey Mouser
Connector TE Connectivity 1-338095-2 - A99497-ND 571-1-338095-2
Crimp terminals TE Connectivity 1-338097-1 1291807 A99491CT-ND 571-1-338097-1
Suggested cable Use 0.2 ~ 0.5 mm² (20 ~24 AWG) flexible wires.
I/O mating connectors
For ribbon cable
The easiest and lowest cost option is using a 16 way flat ribbon cable with 1.27 mm pitch. Please see Pluto
.feedbacks cable
Manufacturer Manufacturer ID Farnell Digikey Mouser
Connector TE Connectivity 8-215083-6 149147 A99458CT-ND 571-8-215083-6
Suggested cable 3M 3302/16 300SF 1369751 MC16M-300-ND 517-C3302/16SF
