EtherCAT input (PORT 1)
Pin Name Description
1 TX_D+ Transmit Data+ line
2 TX_D- Transmit Data- line
3 RX_D+ Receive Data+ line
4 +2V5 2.5 V generated internally
5 +2V5 2.5 V generated internally
6 RX_D- Receive Data- line
7 NC Not connected
8 GND_CHASSIS Connected to the connector chassis
EtherCAT output (PORT 2)
Pin Name Description
1 TX_D+ Transmit Data+ line
2 TX_D- Transmit Data- line
3 RX_D+ Receive Data+ line
4 +2V5 2.5 V generated internally
5 +2V5 2.5 V generated internally
6 RX_D- Receive Data- line
7 NC Not connected
8 GND_CHASSIS Connected to the connector chassis
Wiring and Connections
