Manufacturer Part
Number
Rated
Voltage
(V)
Rated
Current
(A)
Image Description
TDK Lambda PFE500F48 48 10.5 Switching closed
frame power
supply
recommended for
Pluto-5/48, 500 W
TDK Lambda PFE1000F48 48 21 Switching closed
frame power
supply
recommended for
Pluto-8/48, 1000
W
Recommended power supply connection
The recommended power supply connection is shown below. Twisted power supply cables are preferred
to reduce electromagnetic emissions and increase immunity. Distance between line filter and Pluto Servo
Drive should always be minimized.
