Appendix C
-
159
-
Function
Code
Name Setting Range Default Change
F4-10 DI lter time 0.000s to 1.000s 0.010s
☆
F4-11 Terminal I/O control mode
0: Two-wire control mode 1
1: Two-wire control mode 2
2: Three-wire control mode 1
3: Three-wire control mode 2
0
★
F4-12 Terminal UP/DOWN rate 0.001 to 65.535 Hz/s 1.00 Hz/s
☆
F4-13 AI curve 1 min. input 0.00 V to F4-15 0.00V
☆
F4-14
Corresponding
percentage of AI curve 1
min. input
-100.0% to +100.0% 0.0%
☆
F4-15 AI curve 1 max. input F4-13 to 10.00 V 10.00V
☆
F4-16
Corresponding
percentage of AI curve 1
max. input
-100.0% to +100.0% 100.0%
☆
F4-17 AI1 lter time 0.00s to 10.00s 0.10s
☆
F4-18 AI curve 2 min. input 0.00 V to F4-20 0.00V
☆
F4-19
Corresponding
percentage of AI curve 2
min. input
-100.0% to +100.0% 0.0%
☆
F4-20 AI curve 2 max. input F4-18 to 10.00 V 10.00V
☆
F4-21
Corresponding
percentage of AI curve 2
max. input
-100.0% to +100.0% 100.0%
☆
F4-22 AI2 lter time 0.00s to 10.00s 0.10s
☆
F4-23 AI3 curve min. input -10.00V to F4-25 -10.00V
☆
F4-24
Corresponding
percentage of AI curve 3
min. input
-100.0% to +100.0% -100.0%
☆
F4-25 AI curve 3 max. input F4-23 to 10.00 V 10.00V
☆
F4-26
Corresponding
percentage of AI curve 3
max. input
-100.0% to +100.0% 100.0%
☆
F4-27 AI3 lter time 0.00s to 10.00s 0.10s
☆
F4-28 Pulse min. input 0.00kHz to F4-30 0.00kHz
☆
F4-29
Corresponding
percentage of pulse min.
input
-100.0% to 100.0% 0.0%
☆
F4-30 Pulse max. input F4-28 to 100.00 kHz 50.00kHz
☆
F4-31
Corresponding
percentage of pulse max.
input
-100.0% to 100.0% 100.0%
☆
F4-32 Pulse lter time 0.00s to 10.00s 0.10s
☆
F4-33 AI curve selection
Units position: AI1 curve selection
1: Curve 1 (2 points, see F4-13 t o F4-16)
2. Curve 2 (2 points, see F4-18 to F4-21)
3. Curve 3 (2 points, see F4-23 to F4-26)
4. Curve 4 (4 points, see A6-00 to A6-07)
5. Curve 5 (4 points, see A6-08 to A6-15)
Tens position: AI2 curve selection
Hundreds position: AI3 curve selection
321
☆
F4-34
Setting selection when AI
less than min. input
Units position: AI1
0: Corresponding percentage of min. input
1: 0.0%
Tens position: AI2
Hundreds position: AI3
000
☆
F4-35 DI1 delay 0.0s to 3600.0s 0.0s
★
F4-36 DI2 delay 0.0s to 3600.0s 0.0s
★
