Appendix C
-
160
-
Function
Code
Name Setting Range Default Change
F4-37 DI3 delay 0.0s to 3600.0s 0.0s
★
F4-38
DI active mode selection
1
0: High level active
1: Low level active
Units position: DI1 active mode
Tens position: DI2 active mode
Hundreds position: DI3 active mode
Thousand position: DI4 active mode
Ten thousands position: DI5 active mode
00000
★
F4-39
DI active mode selection
2
0: High level active
1: Low level active
Units position: DI6 active mode
Tens position: DI7 active mode
Hundreds position: DI8 active mode
Thousand position: DI9 active mode
Ten thousands position: DI10 active mode
00000
★
Group F5: Output Terminals
F5-00 FM terminal output mode
0: Pulse output (FMP)
1: Digital output (FMR)
0
☆
F5-01 FMR function selection
0: No output
1: AC Drive running
2: Fault output
3: Frequency-level detection FDT1 output
4: Frequency reached
5: Zero-speed running (no output at stop)
6: Motor overload pre-warning
7: AC drive overload pre-warning
8: Set count value reached
9: Designated count value reached
10: Length reached
11: PLC cycle completed
12: Accumulative running time reached
13: Frequency limited
14: Torque limited
15: Ready for RUN
16: AI1 > AI2
17: Frequency upper limit reached
18: Frequency lower limit reached (no output at stop)
19: Undervoltage status output
20: Communication setting
21: Reserved
22: Reserved
23: Zero-speed running 2 (having output at stop)
24: Accumulative power-on time reached
25: Frequency level detection FDT2 output
26: Frequency 1 reached
27: Frequency 2 reached
28: Current 1 reached
29: Current 2 reached
30: Timing duration reached
31: AI1 input limit exceeded
32: Load lost
33: Reverse running
34: Zero current status
35: IGBT temperature reached
36:Software current limit exceeded
37: Frequency lower limit reached (having output at stop)
38: Alarm output
39: Motor overheat warning
40: Current running time reached
41: Fault output (no output at undervoltage)
0
☆
F5-02
Control board relay
function selection
(T/A-T/B-T/C)
2
☆
F5-03
Extension card relay
(P/A-P/B-P/C) function
selection
0
☆
F5-04 DO1 function selection 1
☆
F5-05
Extension card DO2
function selection
4
☆
